IMAGE: Example of EEG signals detected during baseline recording and during the application of convulsant. (a) shows the EEG signal from a fish that hadn’t been treated by anti-epileptic drug (AED)…
view more
Credit: dgist
Before a drug can be used to treat patients, it goes through several rounds of testing for efficacy and toxicity, which begin in animal models. Zebrafish, a tiny species of fish native to South Asia, are cheaper to maintain and easier to breed than laboratory mice or other animal models. They also share many disease-related genes with us, particularly those involved in neurological disorders. This makes them a great model for drug development.
While different experimental methodologies have been developed to study the effects of drugs in zebrafish, they have several major shortcomings. Most notably, behavior monitoring, a popular approach that involves observing the behavior of zebrafish in a tank after administering a drug to them, cannot be used to accurately quantify their neurological responses. Techniques that can be used for more accurate quantification, such as electroencephalography (EEG)–measuring the electrical brain activity non-invasively using surface electrodes or invasively using needle electrodes–have been developed, but these have only been applicable to either larval zebrafish or single adult individuals at a time.
Professor Sohee Kim, from the Department of Robotics Engineering at Daegu Gyeongbuk Institute of Science and Technology (DGIST), Korea, has been pioneering developments in EEGs for zebrafish for the past several years. In a recent study published in Biosensors and Bioelectronics, she led a team to developing a novel system that–for the first time ever–makes it possible to take EEG measurements from multiple adult zebrafish simultaneously.
Their setup makes a key change to existing setups: it separates the drug delivery and fish holding units. Fish are held in several small plastic compartments called “fish fixers,” each of which can hold an anesthetized zebrafish. Drugs and water are transported directly into the mouth of the fish through small tubes at controlled rates. The electrical signals from the fish brains are recorded using flexible electrodes attached on the surface of the fish’s head. With the drug delivery and fish fixing units separated, no physical/environmental artefacts interfere with and hamper the EEG recording process and output, thereby simultaneously yielding clear recordings of the biological effects of the drugs on all the fish in the fixing unit. Yuhyun Lee, Prof Kim’s student and first author of this study, remarks: “Our system is expected to reduce the time and cost at the early stages of drug development and increase success rates when moving on to experiments in mice.”
The team administered an epilepsy-inducing drug to fish that had and hadn’t been given a known anti-epileptic drug called valproic acid beforehand. The EEG readings they then got successfully mapped the changes in the fish’s brain signals during the various degrees of ensuing epileptic attacks, demonstrating that their system could accurately measure the efficacy of this anti-epileptic drug.
Prof. Kim comments, “Using EEG recordings, an accurate and quantifiable measure of brain activity, we expect our system to facilitate the mass screening of drugs for neurological diseases such as sleep disorders, epilepsy, and autism.” This study will hopefully accelerate the development processes of drugs for currently intractable diseases.
###
Reference
Authors: Yuhyun Lee1, Kyeong Jae Lee1, Jae-Won Jang1, Sang-im Lee2, Sohee Kim1,*
Title of original paper:
An EEG system to detect brain signals from multiple adult zebrafish
Journal: Biosensors and Bioelectronics
DOI: 10.1016/j.bios.2020.112315
Affiliations: 1Department of Robotics Engineering, Daegu Gyeongbuk Institute of Science and Technology (DGIST)
2Department of New Biology, DGIST
*Corresponding author’s email: [email protected]
About Daegu Gyeongbuk Institute of Science and Technology (DGIST)
Daegu Gyeongbuk Institute of Science and Technology (DGIST) is a well-known and respected research institute located in Daegu, Republic of Korea. Established in 2004 by the Korean Government, the main aim of DGIST is to promote national science and technology, as well as to boost the local economy.
With a vision of “Changing the world through convergence”, DGIST has undertaken a wide range of research in various fields of science and technology. DGIST has embraced a multidisciplinary approach to research and undertaken intensive studies in some of today’s most vital fields. DGIST also has state-of-the-art-infrastructure to enable cutting-edge research in materials science, robotics, cognitive sciences, and communication engineering.
Website: https:/
About the authors
Prof. Sohee Kim has been trying to seek engineering solutions to medical or biomedical problems for several years. She is particularly interested in developing engineering tools to study the brain and to treat brain diseases and disorders.
Yuhyun Lee, first author of this study, obtained her B.Sc. degree from DGIST in 2018 and then joined Prof Kim’s laboratory at the Department of Robotics Engineering at the DGIST Graduate School. As a student in the engineering department, she, at first, found it very challenging to deal with zebrafish. However, great deal of patience, along with advice from biology professors, helped complete this study.
